Technology
Technical Overview
Frameset
Frame:
Kaius 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | UDH Dropout (Universal Derailleur Hanger) | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC RSM 01 | Integrated Cockpit System Technology
Handlebar:
BMC HB D4 03, 0, 12 | Alloy 6061 | 125mm drop, 70mm reach, 12° flare
Seat
Seatpost:
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Saddle:
Fizik Vento Argo X3 | Kium rails | 140mm
Drivetrain
Crankset:
SHIMANO GRX (FC-RX820-2)
Chainrings:
48-31T
Power Meter:
4iiii Precision Gen3+ Power Meter (Non-Drive Side)
Cassette:
SHIMANO Ultegra (CS-R8101)
Cassette Size:
11-34T
Chain:
SHIMANO CN-M8100
Front Derailleur:
SHIMANO GRX Di2 (FD-RX825)
Rear Derailleur:
SHIMANO GRX Di2 (RD-RX825)
Shifters:
SHIMANO GRX Di2 (ST-RX825)
Gears:
2 x 12
Bottom Bracket:
SHIMANO Press Fit SM-BB72
Brakes
Brake Levers / Calipers:
SHIMANO GRX (BR-RX820)
Rotors:
SHIMANO RT-CL800 | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
CG 40 SL Carbon | Tubeless Ready | 40mm
Hubs (F/R):
CG 40 SL
Tires:
Pirelli Cinturato Gravel H | 40mm
Tubeless Information:
Tubeless Rim | Tubeless Tires
Accessories
In the Box:
Aerocore Design Carbon Bottle Cages
Additional Information
Tire Clearance:
44mm
Weight without Pedals:
8.3 Kg
ASTM Classification:
Level 2
System Weight Limit:
120kg
